Electric, Frequency Relay , Improt/Brand, Relay Sequence
mk-05 phase failure and sequence relay
MK 05 phase failure and sequence relay
MK-05, MKC-05, MK-06, and MKC-06 phase failure devices serve the following protection features.
1. Phase failure2. Phase sequence
3.PTC Protection (only available in MK-05P,MKC-05P,MKC-06P,MK-06P Versions)
4.Voltage unbalance(Both unbalance and delay adjustable)
5. Insufficient supply
SKU: n/a -
Controller, Relay Sequence, Safety Relay, SHIP BREAKING
Safety Relay Pilz PNOZ X3
Safety Relay Pilz PNOZ X3
Safety relay (standalone), inputs: 1/2-channel wiring with/without detection of shorts across contacts, outputs: 3 N/O, 1 N/C,1 SC, automatic/monitored start, UB = 24V AC/24 V DC, width: 45 mm, screw terminals integrated, monitoring of E-STOP, feedback loop, safety gates.SKU: n/a -
-
-
Automation, Improt/Brand, VFD
Nidec Unidrive M700-06400420A 18.5KW/22KW AC Inverter Drive 380/480VAC
Nidec Unidrive M700-06400420A 18.5KW/22KW AC Inverter Drive 380/480VAC Inverter
Motor Shaft Power HD/ND: 18.5kW / 22kW
Motor Shaft Power HD/ND: 30HP / 30HP
Input: Three Phase 380/480VAC
Max Continuous Output Current HD/ND: 42A / 48A
Nidec Unidrive & Accessories (Memomery card, ethernet connector,Software)
Made in UkraineSKU: n/a -
Improt/Brand, minilec, Relay Sequence, Voltage Relay
minilec Phase Failure Relays VSP D2
minilec Phase Failure Relays VSP D2
Supply Voltage
- System100-120/220-240/380-440 V AC ± 20% 50/ 60 Hz
- Auxillary100-120/220-240/380-440 V AC ± 20%
Output Contacts
- Output Contacts2 CO
Trip Setting(Volts)
- Phase SequenceYes
- Phase Unbalance30 V to 70 V ± 6V (adjustable)
Trip Time Delay
SKU: n/a -
Our Valuable Clients
-
Automation, Improt/Brand, VFD
Nidec Unidrive M700-06400420A 18.5KW/22KW AC Inverter Drive 380/480VAC
Nidec Unidrive M700-06400420A 18.5KW/22KW AC Inverter Drive 380/480VAC Inverter
Motor Shaft Power HD/ND: 18.5kW / 22kW
Motor Shaft Power HD/ND: 30HP / 30HP
Input: Three Phase 380/480VAC
Max Continuous Output Current HD/ND: 42A / 48A
Nidec Unidrive & Accessories (Memomery card, ethernet connector,Software)
Made in UkraineSKU: n/a -
Uncategorized
Puls QS40.244 power supply 220-DC24V
Puls QS40.244 power supply 220-DC24V
SHORT-FORM DATA
Output voltage DC 24V nominal
Adjustment range 24 – 28Vdc
Output current 40 – 34.3A continuous
60 – 51.5A short term (4s)
Output power 960W continuous
1440W short term (4s)
Output ripple < 100mVpp 20Hz to 20MHz
Input voltage AC 200-240V -15%/+10%
Mains frequency 50-60Hz ±6%
AC Input current 4.6A at 230Vac
Power factor 0.96 at 230Vac
AC Inrush current 14A peak at 230Vac
Efficiency 94.6% at 230Vac
Losses 54.8W at 230Vac
Temperature range -25°C to +70°C operational
Derating 24W/°C +60 to +70°C
Hold-up time 30ms at 230Vac
Dimensions 125x124x127mm WxHxD
Weight 1800gSKU: n/a -
Automation, VFD
E-TON variable Frequency Drive VFD Inverter 15KW
E-TON variable Frequency Drive VFD Inverter 15KW
ETN260
E-T.N DRIVE
MODEL:ENT260-015G/18R5P-T4
POWER: 15KW
INPUT:3PH AC380V 35A 50HZ/60H2
OUTPUT:3PH AC OV~380V 32A OHZ ~400HZ
E-TON POWER TECHNOLOGY INVERTERAvailable 1.5kw 2.2kw 5.5kw 7.5kw 10kw 15kw 22kw 37kw 55kw 75kw 90kw 110kw
SKU: n/a -
-
Electric, Fuji, Magnetic Contactor
Fuji SC-N3 Magnetic Contactor 3Pole 100A
Fuji SC-N3 Magnetic Contactor 3Pole 100A
Product: Magnetic Contactor
Voltage: 220 VAC (other voltages also available)
Number of poles: 3
Thermal current: 100A
Current at 440 vac: 65
Power: 30 KW / 40 HP
Made in Japan
Product series: SC series
Scope of application: Outdoor / Indoor
Coil frequency: 50/60 Hz
SKU: n/a -
-
Automation, Electric, Frequency Relay , Power Supply
infineon ff300r13ke3 igbt 1200 V 300 A dual IGBT module
Automation, Electric, Frequency Relay , Power Supplyinfineon ff300r13ke3 igbt 1200 V 300 A dual IGBT module
infineon ff300r13ke3 igbt 1200 V, 300 A dual IGBT module
62 mm 1200 V, 300 A dual IGBT module with fast TRENCHSTOP™ IGBT3 and Emitter Controlled high-efficiency diode is the right choice for your design.
Configuration Dual Dimensions (width) 61.4 mm Dimensions (length) 106.4 mm Housing 62 mm IC(nom) / IF(nom) 300 A IC max 300 A Qualification Industrial Technology IGBT3 – T3 VCE(sat) (Tvj=25°C typ) 1.7 V VF (Tvj=25°C typ) 1.65 V Voltage Class max 1200 V SKU: n/a -
Automation, Controller, Frequency Relay
ROTARY ENCODER FA-CODER TAMAGAWA OIH 48-2500P8-L6 5V-215
ROTARY ENCODER FA-CODER TAMAGAWA OIH 48-2500P8-L6 5V-215
Model: 48-2500P8-L6-5V
48-2500P8-L6 Pulse: 2500c/t
Working temperature: 20-85
Shaft Diameter: 7.5-9.0mm
Working voltage: 5V
48-2500P8-L6 Signal Classification: Incremental
Humidity: 90% RH
SKU: n/a
